DUE 2012 R3 84 MHz 800 mA 3.3V 512 KB 96 KB SRAM Board for Aduino

Brand Name : OEM

Model Number : oky2005

Place of Origin : Guangdong China (Mainland)

MOQ : 1 Piece/Pieces

Payment Terms : L/C, D/A, T/T, Western Union, MoneyGram

Supply Ability : 1000 Piece/Pieces per Day

Delivery Time : 3-5 workdays after payment

Packaging Details : Standard package

Input Voltage (recommended) : 7-12V

Digital IO pins : 54 (of which 12 provide PWM output)

Analog input pins : 12

DC Current per I/O Pin : 800 mA

SRAM : 96 KB (two banks: 64KB and 32KB)

Operating voltage : 3.3V

Clock Speed : 84 MHz

Flash Memory : 512 KB all available for the user applications

Contact Now

High quality with factory price! DUE 2012 R3 Board for Aduino Newest Development Board

Description:

TheDue is a microcontroller board based on the Atmel SAM3X8E CPU, which is the first one based on 32bit ARM core arduino. The Arduino Due has 54 digital input/output pins (of which 12 can be used as PWM outputs), 12 analog inputs, 4 UARTs (hardware serial ports), an 84 MHz clock, a USBOTG capable connection, 2 DAC (digital to analog), 2 TWI, a power jack, an SPI header, a JTAG header, a reset button and an erase button.

Features:

Microcontroller:AT91SAM3X8E
Operating Voltage:3.3V
Input Voltage (recommended):7-12V
Input Voltage (limits):6-16V
Digital I/O Pins:54 (of which 12 provide PWM output)
Analog Input Pins:12
Analog Outputs Pins:2 (DAC)
Total DC Output Current on all I/O lines:130 mA
DC Current for 3.3V Pin:800 mA
DC Current for 5V Pin:800 mA
Flash Memory:512 KB all available for the user applications
SRAM:96 KB (two banks:64KB and 32KB)
Clock Speed:84 MHz

Photos:

DUE 2012 R3 84 MHz 800 mA 3.3V 512 KB 96 KB SRAM Board for Aduino
